Evolis Sig100 Lite Signature Capture Pad ST-LTE105-2-UEVL

Evolis Sig100 Lite Signature Capture Pad ST-LTE105-2-UEVL

MSRP: $140.00
$133.00 ea. $133.00 ea.

Bulk Ordering? Complex Project? Click Here.

Currently, we have 0 available. Please contact us to inquire about lead times. Sorry, this item is currently out of stock, please contact us to confirm lead times and availability. You can click here to discover additional alternative recommendations.


  • Part number: ST-LTE105-2-UEVL
  • Cost-effective design without LCD screen, ideal for basic signature capture
  • Durable writing surface for precise signatures, displayed in real-time on the computer
  • Secure AES and RSA encryption for safe data transfer and storage
  • Compatible with a wide range of operating systems and easy USB interface
View full details


The Sig100 LITE is a cost-effective signature pad designed without an LCD screen, featuring a durable writing surface for precise signature capture. The signature appears in real-time on the computer monitor, making it an ideal solution for applications where only the signature is required. Its slim and ergonomic design, coupled with advanced security measures and compatibility with various operating systems, makes the Sig100 LITE a reliable and efficient choice for signature capture.

Part Number ST-LTE105-2-UEVL
Supported OS
  • Windows® XP 32/64
  • Windows® 7 32/64
  • Windows® 8 32/64
  • Windows® 10 32/64
  • Windows® Server 2003, 2008, 2010
  • Linux
Certifications TUV, CE, FCC, RoHS, EN 60950-1, EN 61000-6-1, EN 61000-6-3
Protection Class IP52
Active Signing Area 95 x 47 mm
Resolution 4036 x 4036 pixels / 2214 x 1130 ppi
Pressure Levels 1024
Signature Digitization 500 Hz external, 6000 Hz internal sampling rates
Security AES and RSA encryption, Unique internal serial number
Dimensions 10 x 160 x 120 mm (0.39’’ x 6.29’’ x 4.72’’)
Weight 200 g (0.44 lbs)
Interface Full-speed USB 2.0 HID
Power Via USB cable
Software Compatible with signoSign/2 (Sold Separately), Free SDK and Twain driver available
Warranty 2 years
