Professional credentials, printed at your desk
The HID FARGO Connect Enabled HDP5000e, part number 078107 (also listed as 78107), is the dual-sided model built for HID's FARGO Connect cloud card-issuance platform. Instead of installing printer drivers on individual workstations, card offices design templates, capture data, and issue cards from any supported device through FARGO Connect's secure cloud or on-premises platform - with real-time printer visibility, consumables monitoring, and remote issuance to distributed locations.
The hardware is the proven HDP5000e retransfer engine: high-definition 600 dpi printing onto HDP film that is fused to the card for true over-the-edge coverage on technology cards, with USB 2.0 and Ethernet standard and AES-256 encryption with resin scramble data protection guarding cardholder data.
Please note: FARGO Connect Enabled printers operate through the HID FARGO Connect platform, which requires a FARGO Connect Console and an annual FARGO Connect subscription, sold separately. Contact Specialist ID before ordering and we will help configure the complete solution for your card program. The printer carries HID's standard HDP5000e factory warranty (see specifications).
Consumables
A complete list of compatible consumables for the HID FARGO Connect HDP5000e. Click any part number for details.
| Part Number | Description and Yield |
|---|---|
| 084511 | HID FARGO YMCK Ribbon, 500 Prints |
| 084512 | HID FARGO YMCKK Ribbon, 500 Prints |
| 084510 | HID FARGO YMC Ribbon, 750 Prints |
| 084514 | HID FARGO YMCFK Ribbon, 500 Prints |
| 084518 | HID FARGO Premium Black (K) Ribbon, 3000 Prints |
| Part Number | Description and Yield |
|---|---|
| 084500 | HID FARGO Clear HDP Retransfer Film, 1500 Prints |
| 084501 | HID FARGO Holographic HDP Film, 500 Prints |
| Part Number | Description |
|---|---|
| SPID-8670-WHITE | Specialist ID Composite PVC/PET Cards, CR-80 30mil |
| 082136 | HID FARGO UltraCard Premium Composite (500) |
| 082137 | HID FARGO UltraCard Composite HiCo Mag (500) |
| 082289 | HID FARGO UltraCard PC Polycarbonate (500) |
Technical Specifications
- Platform
- HID FARGO Connect cloud card issuance (FARGO Connect Console + annual subscription required, sold separately)
- Print method
- HDP dye-sublimation / resin thermal transfer (retransfer)
- Resolution
- 300 dpi (11.8 dots/mm)
- Colors
- Up to 16.7 million / 256 shades per pixel
- Print ribbon options
- YMC 750 prints; YMCK 500 prints; YMCKK 500 prints; YMCFK 500 prints; K resin black 3,000 prints
- HDP film options
- Clear 1,500 prints; standard holographic 500 prints
- Print speed
- Batch mode: 20 sec/card YMC (178 cph); 27 sec/card YMCK (133 cph); 33 sec/card YMCKK (109 cph)
- Printing capability
- Dual-sided printing
- Security features
- Resin scramble data protection; password protection; TLS encryption; fluorescent (UV) panel printing
- Accepted card sizes
- CR-80 (3.375 in L x 2.125 in W)
- Print area
- Over-the-edge on CR-80
- Accepted card thickness
- 30-50 mil
- Accepted card types
- ABS, laminated PVC, PET, PETG, proximity, smart, and magnetic stripe cards
- Input card cartridge
- 100 cards (30 mil); optional dual input or 200-card hopper for 200-card capacity
- Output hopper
- 200 cards (30 mil)
- Card cleaning
- Replaceable cleaning roller included with each print ribbon
- Memory
- 1 GB RAM
- Display
- Graphical OLED
- Interface
- USB 2.0 (high speed); Ethernet with internal print server
- Software
- Driverless issuance through the HID FARGO Connect platform
- Software
- Diagnostic utility with Color Assist spot-color matching (included with driver)
- Operating temperature
- 65 to 90 F (18 to 32 C)
- Humidity
- 20-80% non-condensing
- Dimensions
- 12 in H x 22 in W x 11 in D
- Weight
- 28.6 lbs
- Supply voltage
- 100-240 VAC, 1.6 A, 50/60 Hz
- Certifications
- UL, CE, FCC, IC
- Warranty
- 4-year printer warranty with 1 year of U.S. loaner coverage; lifetime printhead warranty
Compatible Supplies
Genuine HID Fargo ribbons and supplies matched to the HDP5000e (FARGO Connect).
